1.Main application is for kinds of sideflexing conveyor.
2.Temperature range: -40℃~90℃.
3.Plates material: POM.
4.Color: brown.
5.Roller base chain: standard 12A roller chain.
6.Material: carbon steel(CS) or stainless steel(SS).
7.Max speed: 50m/min lubrication 30m/min dry.
8.Working load: 3200N (mat.: CS), 1600N (mat.: SS).
9.Max conveying length: 30m (mat.: CS), 24m (mat.: SS).
Specification:
| Code | Plates width（mm） | Weight（Kg/m） | Backflex R（mm） | Min.Radius（mm） | |
| CS | SS | ||||
| 1873-K325 | 1873SS-K325 | 82.6 | 2.10 | 150 | 356 |
| 1873-K450 | 1873SS-K450 | 114.3 | 2.26 | 150 | 356 |
| 1873-K600 | 1873SS-K600 | 152.4 | 2.41 | 150 | 457 |
| 1873-K750 | 1873SS-K750 | 190.5 | 2.56 | 150 | 457 |
| 1873-K1000 | 1873SS-K1000 | 254 | 2.78 | 150 | 457 |
| 1873-K1200 | 1873SS-K1200 | 304.8 | 3.01 | 150 | 457 |
