Main application is for transportation of cans, plastic bottles,cans and cartons in e.g. dairy and brewery.
Material: POM, color: white, temp.: -40℃~90℃
Pin material: cold-rolled austenitic stainless steel.
Max speed: 80m/min with lubrication, 50m/min dry.
Working load(25°): 2100N, max conveying length: 15m.
| Code | Width（mm） | Weight（Kg/m） | Backflex R（mm） | Min. radius（mm） |
| Rt1400 | 114.3 | 1.3 | 75 | 610 |
