Features&Benefits
- 90 degree design makes the connections more diverse.
- High input speed allows 6000 rpm.
- High reduction ratio:Modular design can make the ratio reach 1/1000.
- Various input design allows reducers can be connected with all servo motor models.
Tecnical Feature
- Size from 60 to 160
- Ratio range from 3 to 1000
- Backlash 1 stage ≤12 arcmin /2 stage ≤15 arcmin/3 stage ≤18 arcmin
- Efficiency 90-94%
- Noise(Max) 55-68 db
- Service Life 20000h
- Nominal input speed 3000-4000 rpm
- Max.input speed 4500-8000 rpm
